Imada ZTS Series User Manual

page 25
Zero Button Zero the force value on the force gauge
Peak Capture peak value
Zero Both Button Zero both force and displacement values on
the force gauge
Capture Value Button Captures and displays data in table
Start Continuous Capture Start capturing continuous data at
10 data/second max.
Stop Continuous Capture Stops continuous data capture
Data Table Displays captured data
Copy Copy data table to clipboard
Statistics Displays statistics of acquired data
Go/No Go Displays number of +NG
Connection/Operation Status Gauge is connected or discon-
nected in Peak or Real Time mode
13
14
15
16
17
18
8
9
11
12
10
1 2 3 4 5
6
7
8
9
10
18
11
12
13
14
15
16
17

Imada ZTS Series Specifications

General

Display	LCD
Sampling Rate	2000 Hz
Measurement Units	N, kgf, lbf
Data Output	USB, RS-232
Power Supply	AC adapter or battery
Battery Life	Approx. 8 hours
Operating Temperature	0°C to 40°C
Storage Temperature	-10°C to 50°C (14°F to 122°F)
Accuracy	+/- 0.2% F.S.
