Y-(K+Pn-3)
V-(K+Pn-4)
Y-(K+Pn-2)
Y-(K+Pn-1)
<Mono 8/GR8 Format>
Y-(K+0)
Y-(K+1)
Y-(K+2)
Y-(K+3)
Y-(K+4)
Y-(K+5)
Y-(K+6)
Y-(K+7)
Y-(K+Pn-8)
Y-(K+Pn-7)
Y-(K+Pn-6)
Y-(K+Pn-5)
Y-(K+Pn-4)
V-(K+Pn-3)
Y-(K+Pn-2)
Y-(K+Pn-1)
<Mono 12/ GR12 Format>
High Byte
Low Byte
Y-(K+0)
Y-(K+1)
Y-(K+2)
Y-(K+3)
Y-(K+Pn-4)
Y-(K+Pn-3)
V-(K+Pn-2)
Y-(K+Pn-1)
Data Structure
<Y, R, G, B>
Each component has 8 bits of data. The data type is “Unsigned Char”
Signal Level (Decimal)
Data (Hexadecimal)
Highest
255
0xFF
254
0xFE
.
.
.
.
1
0x01
Lowest
0
0x00
<U, V>
Each component has 8 bits of data. The data type is “Straight Binary”
Signal Level (Decimal)
Data (Hexadecimal)
Highest(+)
127
0xFF
126
0xFE
.
.
.
.
