3.2.3. IMC-7020G Specification
Features (IMC-7020G)
Image Sensor
1/1.8” Interline CCD(ICX274AQ)
Effective Pixels
2,012,208 pixels 1628(H) x 1236(V)
Picture Size
1624 x 1232
Cell Size
4.4 um x 4.4 um
Real Frame Rate
16 (1624x1228, GR8)
8 (1624x1228, GR12)
14 (1624x1228, YUV411)
8 (1624x1228, YUV422)
30 (800x600, 2x2 binning, GR8)
15 (800x600, 2x2 binning, GR12)
.9(800x600, 2x2 binning, GR12)
Lens Mount
C-mount, CS-Mount
Scanning System
Progressive System
Binning
2x2
Partial Scan
(Unit: 4x4)
Trigger
Edge
Rising Edge or Falling Edge
Mode
0, 1, 2, 4, 5, 12, 13, 15
Source
External Trigger(Photo-coupler) or Software Trigger
Strobe
Support Normal Mode or Trigger Mode. (Photo-coupler)
Memory Save/Load
9 Channels (0:factory, 1~4:feature, 5~8:mode/feature)
One-shot/Multi-shot
1 Shots ~ 65535 Shots
Control Functions
Brightness, Sharpness, Gamma, Auto-Exposure, Shutter, Gain,
White Balance, User Defined LUT, Auto-Iris Control
SIO(RS-232)
Path through or IMI-Tech Command
Digital Interface / Transfer Rate
1000BT, RJ45 / 1Gbps
Gain
0 ~ 18 dB(Manual or Auto control)
Shutter Speed
1 usec ~ 3600 sec (Manual or Auto control)
Data Depth
12 bit
S/N Ratio
56dB or better
Supply Voltage& Power
Less than 3 Watts (@12V DC)
External Dimension / Weight
40(W) x 40(H) x 48(D) mm / Approx 125g
Operation Temp / Storage Temp.
-5°C to 45°C / -30°C to 60°C
Camera Specification
AIA GigE Vision version 1.0
