AMAZON SERIES Operation Manual
Pioneer i n D i g i t al V is io n Technol og y
3.2.7. IMC-7015G Specification
Features(IMC-7015G)
Image Sensor Type
1/3” Interline CCD (ICX204AK)
Effective pixels
805,486 pixels 1034(H) x 779(V)
Picture Size
1028 x 772
Cell Size(um)
4.65 um x4.65 um
Real Frame Rate
36 (1028x772, GR8)
18 (1028x772,GR12)
31 (1028x772, YUV411)
18 (1028x772, YUV422)
Lens Mount
C-Mount, CS-Mount
Scanning System
Progressive System
Binning
Not support
Partial Scan
(Unit: 4x4)
Trigger
Edge
Rising Edge or Falling Edge
Mode
0, 1, 2, 4, 5, 12, 13, 15
Source
External Trigger (Photo-coupler) or Software Trigger
Strobe
Support Normal Mode or Trigger Mode. (Photo-coupler)
Memory Save/Load
9 Channels (0:factory, 1~4:feature, 5~8:mode/feature)
One-shot/Multi-shot
1 shot ~ 65535 Shots
Control Functions
Brightness, Sharpness, Gamma, Auto-Exposure, Shutter, Gain
White Balance, User Defined LUT, Auto-Iris Control
SIO(RS-232)
Path through or IMI-Tech Command
Digital Interface / Transfer Rate
1000BT, RJ45 / 1Gbps
Gain
0 ~ 18 dB(Manual or Auto control)
Shutter Speed
1 usec ~ 3600 sec(Manual or Auto control)
Data Depth
12 bit
S/N Ratio
56dB or better
Supply Voltage& Power
Less than 3 Watts (@12V DC)
External Dimension / Weight
40(W) x 40(H) x 48(D) mm / Approx 125g
Operation Temp. / Storage Temp.
-5°C to 45°C / -30°C to 60°C
Camera Specification
AIA GigE Vision version 1.0
Remark: Camera specification described above may be changed without notice
