Status Control Register
Address
Name
Field
Bit
Description
F0F00834h
TRIGGER_DELAY
Presence_Inq
[0]
Presence of this feature
0: N/A 1: Available
Abs_Control
[1]
Absolute value control
0: Control with value in Value field
1: Control with value in Absolute value
CSR if this bit =1, value in Value filed is
ignored
-
[2..5]
Reserved
ON/OFF
[6]
Write : ON or OFF this feature
Read : read a status
0: OFF, 1:ON
If this bit=0, other fields will be read only.
-
[7..19]
Reserved
Value
[20..31]
Minimum value for this feature control
4.11.1. Strobe Delay / Duration Table
The table shows the strobe index by increment step through the strobe delay time and the strobe duration time.
The increment step is different depending on the strobe index.
Strobe Delay Table
Strobe Index (Y)
Increment Step
Strobe Delay Time
Delay Time
Range
0 ~ 3900
1 us
T=Y us
0 ~ 3900 us
Strobe Duration Table
Strobe Index (Y)
Increment Step
Strobe Delay Time
Delay Time
Range
1 ~ 200
250 us
T=Y*250 us
250 us ~ 50 ms
Index and Time Table for Strobe Delay and Duration
Delay Index (Y)
Strobe Delay Time
Duration Index (Y)
Strobe Duration Time
0
0 us
1
250 us
1
1 us
2
500 us
2
2 us
3
750 us
10
10 us
4
1 ms
100
100 us
10
2.5 ms
1000
1000 us
100
25 ms
3900
3900 us
200
50 ms
