AMAZON SERIES Operation Manual
Pioneer i n D i g i t al V is io n Technol og y
DAC Control register
Bit 0: Presence inquiry (read only)
Bit 4: Exposure feature value DAC output enable for calibration or test
Bit 5: Exposure feature reference mode enable
[Bit 4: Bit 5]
00: DAC output = Frame Brightness
01: DAC output = Frame Brightness – Auto_Exposure + 128
10: DAC output = Frame Brightness – Auto_Exposure + 128
10: DAC output = Auto_Exposure
% Auto_Exposure : address 0xF0F0804 feature value
Bit 6: DAC run/hold (1: run, 0: current value hold)
Bit 9~Bit 15: # of frames for DAC average (valid value : 0,1,2,4,8,16,32,64)
*msb: most significant bit and bit 0 is msb.
*msb: 0 is the most significant bit
7. Video Formats and Modes
The Amazon series supports scalable image size for video modes which is similar to the Firewire IIDC 1.31 Format 7
Mode. Supported resolutions per cameras are listed in Section 7.1.
An overview of these formats is as follows;
The Amazon Series supports scalable video size with the following base address:
Format 7 Mode 0: F1F00000h Format 7 Mode 1: F1F00100h
Maximum Horizontal / Vertical pixel number
Horizontal and Vertical unit pixel number
Left / Top position of requested image region (pixel)
Width / Height of the requested image region (pixel)
Inquiry register for color information setting
Higher quadlet of total bytes of image data per frame
