3.1.7. IMB-7015G Specification
Features(IMB-7015G)
Image Sensor Type
1/3” Interline CCD (ICX204AL)
Effective pixels
805,486 pixels 1034(H) x 779(V)
Picture Size
1032 x 776
Cell Size(um)
4.65 um x4.65 um
Real Frame Rate
36 (1032x776, Mono 8)
18 (1032x776,Mono 12)
65 (512x384, 2x2 binning, Mono 8)
33 (512x384, 2x2 binning, Mono 12)
Lens Mount
C-mount, CS-Mount
Scanning System
Progressive System
Binning
2x2
Partial Scan
(Unit: 4x4)
Trigger
Edge
Rising Edge or Falling Edge
Mode
0, 1, 2, 4, 5, 12, 13, 15
Source
External Trigger (Photo-coupler) or Software Trigger
Strobe
Support Normal Mode or Trigger Mode. (Photo-coupler)
Memory Save/Load
9 Channels (0:factory, 1~4:feature, 5~8:mode/feature)
One-shot/Multi-shot
1 shot ~ 65535 Shots
Control Functions
Brightness, Sharpness, Gamma, Auto-Exposure, Shutter, Gain,
User Defined LUT, Auto-Iris Control
SIO(RS-232)
Path through or IMI-Tech Command
Digital Interface / Transfer Rate
1000BT, RJ45 / 1Gbps
Gain
0 ~ 18 dB(Manual or Auto control)
Shutter Speed
1 usec ~ 3600 sec(Manual or Auto control)
Data Depth
12 bit
S/N Ratio
56dB or better
Supply Voltage& Power
Less than 3 Watts (@12V DC)
External Dimension / Weight
40(W) x 40(H) x 48(D) mm / Approx 125g
Operation Temp. / Storage Temp.
-5°C to 45°C / -30°C to 60°C
Camera Specification
AIA GigE Vision version 1.0
Remark: Camera specification described above may be changed without notice
