AMAZON SERIES Operation Manual
Pioneer i n D i g i t al V is io n Technol og y
4.9.4. Trigger & Strobe delay
For Amazon series, the strobe signal starting point is almost the same as the exposure starting point
4.9.5. Trigger Mode 0
The camera starts the integration of the incoming light from the external trigger input falling edge. Integration
time is described in the “Shutter" register. No parameter is needed. A Trigger delay is applied to mode 0 for H/W
trigger. The Trigger in mode 0 is supported by both a H/W trigger and a S/W trigger.
The trigger delay start time is strobe delay start time.
Trigger Delay / Strobe Delay
