5.5.7. SIO(RS232) IMI TECH Commands
0xF2F10018
Auto-Sync Mode control register
Bit 30: SIO enable mode (0 : IMI-TECH mode, 1)
Read/Write
IMI Tech Commands are valid when the Bit30 is set to “0”(zero).
SIO(RS232) IMI Tech commands are a specific mode for IMI cameras. Before using these commands, serial
communication parameters must be set at Serial_Mode_Reg (F2F22000h).
F2F10018 means that the RS232 command is valid.
Baud Rate
Stop Bit
Parity
Flow Control
57600 bps (default)
1 bit
None
Non
 Command format : [STX] [Command] [Data] [ETX]
[STX] : Command start character: ‘S’
Command] : Command length is 2byte. See next page command table.
[Data] : Data length is varied with each command. Data format is hexadecimal: ‘0’~’9’, ‘A’~’F’.
[ETX] : Command end character: ‘Z’
 Return value
‘G’ : Command complete acknowledge.
“Gdd..Z” : “Gdd..Z” is return data and a hexadecimal character.
‘U’ : Undefined command.
 Valid Character : ‘0’~’9’, ‘A’~’F’, ‘S’, ’Z’ Any invalid character that is received, is discarded.
 (example) Gain setting command with 0x200 value.
All of “SA0200Z”, “S A0 200 Z”, “SA0 200Z”, “S A0200 Z”, and “SKA0V200Z” are parsed to “SA0200Z Z”, and
“SKA0V200Z” is parsed to “SA0200Z”.
