If Polarity_Inq is “0” Read only ( 0: lowa
active output, 1: High active output)
Delay_Value
[8..19]
Delay after start of exposure until the
strobe signal asserts
Duration_Value
[20..31]
Duration of the strobe signal
A value 0 means dessert at the end of
exposure function if required.
204h
Strobe_1_Cnt
Same definition to Strobe_0_Inq
208h
Strobe_2_Cnt
Same definition to Strobe_1_Inq
20Ch
Strobe_3_Cnt
Same definition to Strobe_2_Inq
210h
.
.
2FFh
Reserved
4.11. Trigger Delay Control
Based on external triggers, the users can delay image acquisition by the trigger delay control feature. The Amazon
Series supports trigger delay control as per the following tables. There is no support in software trigger
mode.
Trigger Delay Table
Mode
Value range
Trigger delay Time : T
DelayTime
Range
All Cameras
0 ~ 4000
T = Yus
0 usec ~ 4000 usec
Inquiry Register
Address
Name
Field
Bit
Description
F0F00534h
TRIGGER_DLY_IN
Q
Presence_Inq
[0]
Presence of this feature
Abs_Control_Inq
[1]
Capability of control with absolute value
-
[2]
Reserved
One_Push_Inq
[3]
One push auto mode (Controlled
automatically by camera only once)
ReadOut_Inq
[4]
Capability of reading the value of this
feature
ON/OFF_Inq
[5]
Capability of switching this feature ON and
OFF
Auto_Inq
[6]
Auto Mode (Controlled automatically by
camera)
Manual_Inq
[7]
Manual Mode (Controlled by user)
Min_Value
[8..19]
Minimum value for this feature control
Max_Value
[20..31]
Maximum value for this feature control
