AMAZON SERIES Operation Manual
Pioneer i n D i g i t al V is io n Technol og y
0: Control with value in Value field
1: Control with value in Absolute value
CSR if this bit =1, value in Value filed is ignored
Write ‘1’: begin to work (Self cleared after the
operation)
Read : Value=’1’ in operation
Value =’0’ not in operation
If A_M_Mode=1, this bit is ignored
Write: ON or OFF this feature
Read: read a status
0: OFF, 1: ON
If this bit=0, other fields will be read only.
Write: Set the mode
Read: Read a current mode
0: Manual, 1: Auto
Minimum value for this feature control
4.2. Auto Exposure Control
The automatic shutter/gain mode is based on a feedback loop which calculates the average pixel luminance. Then
the average is compared with the exposure reference value, adjusting shutter and gain accordingly. This feature is
similar to “Contrast Control”
Inquiry Register
Capability of control with absolute value
One push auto mode (Controlled automatically by
camera only once)
Capability of reading the value of this feature
Capability of switching this feature ON and OFF
Automode (Controlled automatically by camera)
Manual mode (Controlled by user)
Minimum value for this feature control
Maximum value for this feature control
Status Control Register
Presence of this feature
0: N/A, 1: Available
Absolute value control
0: Control with value in the Value field
1: Control with value in the Absolute value CSR
If this bit = 1, value in the Value field is ignored.
Write ‘1’ :begin to work(Self cleared after
operation)
Read: Value=’1’ in operation Value=’0’ not in
operation
If A_M_Mode =1, this bit is ignored
Write: ON or OFF this feature,
