If this bit = 1, value in the Value field is ignored.
-
[2..4]
Reserved
One_Push
[5]
Write ‘1’ :begin to work (Self cleared after
operation)
Read: Value=’1’ in operation
Value=’0’ not in operation
If A_M_Mode =1, this bit is ignored
ON_OFF
[6]
Write: ON or OFF this feature,
Read: read a status
0: OFF, 1: ON
If this bit=0, other fields will be read only.
A_M_Mode
[7]
Write: set the mode,
Read: read a current mode
0: Manual, 1: Auto
-
[8..19]
U Value / B_Value.
Write the value in AUTO mode, this field is
ignored.
If “ReadOut” capability is not available,, read
value has no meaning.
Value
[20..31]
V Value / R_Value
Write the value in AUTO mode, this field is
ignored.
If ”ReadOut” capability is not available, read value
has no meaning
