AMAZON SERIES Operation Manual
Pioneer i n D i g i t al V is io n Technol og y
Mode control register
Bit 30: SIO enable mode (0: IMI-TECH mode, 1: path through)
Trigger noise filter register (External trigger only)
Bit 22~Bit 31: trigger masking range (M, unit: usec, range: 0~999)
Power on default memory channel
Bit 0 ~ Bit 3: power on initial memory channel
Camera version register
Bit 16~Bit 31: camera version
(ex: If reading value: 0x00003000, camera version is 3.000)
Bright Level for Iris Control Application
Bit 24 ~ Bit 31: Bright Level for Image Capture
Test Pattern
Bit 0: Vertical Grey Bar
Bit 1: Bias Grey Bar
4 step knee LUT run control register
LUT knee 1st point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit4: reserved
Bit 5: enable brightness, sharpness, gamma feature with knee function
Bit 6: On/Off
Bit 7: reserved
Bit 8~Bit 19: X coordination of 1st knee point
Bit 20~Bit31: Y coordination of 1st knee point
LUT knee 2nd point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit5: reserved
Bit 6: reserved
Bit 7: reserved
Bit 8~Bit 19: X coordination of 2nd knee point
Bit 20~Bit31: Y coordination of 2nd knee point
LUT knee 3rd point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit5: reserved
Bit 6: reserved
Bit 7: reserved
Bit 8~Bit 19: X coordination of 3rd knee point
Bit 20~Bit31: Y coordination of 3rd knee point
LUT knee 4th point register
Bit 0: presence inquiry (read only)
Bit 1: LUT regeneration command (self cleared)
Bit 2~Bit5: reserved
Bit 6: reserved
Bit 7: reserved
Bit 8~Bit 19: X coordination of 4th knee point
Bit 20~Bit31: Y coordination of 4th knee point
User defined LUT run control register
Bit 0: presence inquiry (read only)
Bit 1~Bit 4: reserved
Bit 5: enable brightness, sharpness, gamma feature with user defined LUT
function
Bit 6: ON/OFF
