5 sErvicEability
Service Manual
Yate Production Dryers
Edition
2006.09.21
h) Removal of drum reversing timerf) Removal of drum
1.
Complete all steps necessary in order to remove
the belt
2.
Remove the rear belt and separate the drum
shaft from the rear panel; the drum can now be
removed from the casing
1. Undo the two screws securing the timer to the
base
