50 Equipment Settings
4 Equipment Settings
4.1 Menu Structure
By pressing the menu button the main menu page opens. The following options will
be displayed:
In the subsequent sub-menus the following frequently used functions will occur:
The menu structure of the main menu is illustrated on the following page for quick
reference.
Fig. 39 Main menu screen
The “up” and “down” keys allow scrolling through listed menu items. The
currently selected menu item is highlighted by inverted colours. The “up”
and “down” keys are also used for changing numerical values to a new
setting.
? Help function – by pressing this key additional information on how to use
this page can be displayed.
Esc Going back to the previous page while omitting any changes.
Back Going back to the next higher level in the menu structure.
OK Accepting a selected item from a list or accepting newly entered values.
Exit all menus and return to main screen. If the menu button is pressed later
on again, the software will jump to the menu page that has been exited by
the button. By pressing the back key the display will go back one level
and finally all the way back to the measurement display page.
