Inficon VGC083A User Manual (English)

Questions and Answers:

E
emilyjenkinsAug 4, 2025
What to do if my Inficon Controller shows EMIS FAIL?
- G
  gbrownAug 5, 2025
  If the Inficon Controller displays 'EMIS FAIL', it means the desired emission current couldn't be established, possibly due to gauge contamination, the end of filament life, or the system pressure being too high. Try switching to a 4 mA or 10 mA emission current and repeatedly start the filament to clean it. If that doesn't work, switch to the second filament and degas. If the problem persists, the ion gauge sensor tube may need replacement. Also, ensure that the system pressure is reduced to an acceptable level.
M
Michelle OrtegaAug 10, 2025
What to do if Inficon VGC083A displays OVERPRESSURE?
- T
  Terri MirandaAug 10, 2025
  If your Inficon Controller shows 'OVERPRESSURE', it indicates that the calculated pressure exceeds the maximum setting for the emission current, or the system pressure is too high. To resolve this, you can switch to a 100 µA emission current, which allows operation at higher pressures. Alternatively, reduce the system pressure to an acceptable level.
T
Tanya CurryAug 17, 2025
What does F1 or F2 OPEN mean on my Inficon VGC083A?
- K
  kathleen64Aug 17, 2025
  If the Inficon Controller displays 'F1 or F2 OPEN', this indicates that either Filament 1 or Filament 2 is open, or there is a faulty electronics. You can try switching to the other filament or replacing the Ion gauge sensor tube. If that doesn't work, replace electronics.
S
Steven WilliamsAug 23, 2025
What to do if Inficon VGC083A Controller shows CONNECT IG COMM IO FAIL?
- M
  Monica HaynesAug 23, 2025
  If the Inficon Controller shows 'CONNECT IG COMM IO FAIL', it means the IG is not connected, the cable is faulty, or the internal PCB is not communicating. Ensure the IG is properly plugged in. If it is, try replacing the cable.
M
mooredavidAug 28, 2025
How to fix OVER TEMP error on Inficon Controller?
- D
  Danielle DavisAug 28, 2025
  If the Inficon Controller displays 'OVER TEMP', it means the ion gauge cable is longer than 50 ft. To fix this, reduce the cable length to less than 50 ft. or provide airflow around the VGC083.
