InFocus X16 Reference Guide

Operation36
Menu operation
Menu system
Please note that the on-screen display (OSD) menus vary according to the signal
type selected.
The menu items are available when the projector detects at least one valid signal. If
there is no equipment connected to the projector or no signal detected, limited
menu items are accessible.
Main menu Sub-menu Options
1.
DISPLAY
Wall Color
Off/Light Yellow/Pink/Light
Green/Blue/Blackboard
Aspect Ratio Auto/Real/4:3/16:9
Keystone
Position
Phase
H. Size
Digital Zoom
2.
Preset Mode
PC source: Brightest/Presentation/Photo/Cinema/
User 1/User 2
Video source: Brightest/Standard/Cinema/User 1/
User 2
Reference Mode
PC source: Brightest/Presentation/Photo/Cinema
Video source: Brightest/Standard/Cinema
Brightness
Contrast
Color
Tint
Sharpness
Brilliant Color On/Off
Color Temperature T1/T2/T3/T4
3D Color
Management
Primary Color R/G/B/Y/C/M
Hue
Saturation
Gain
Save Settings
3. SOURCE
Quick Auto Search On/Off
4.
SYSTEM
SETUP:
Basic
Presentation
Timer
Timer Period 1~240 minutes
Timer Display Always/1 min/2 min/3 min/Never
Timer Position
Bottom-right/Top-right/Bottom-
left/Top-left
Timer Counting
Direction
Count Down/Count Up
Sound Reminder On/Off
On/Off

InFocus X16 Specifications

Display

native resolution	800 x 600
display technology	0.55” LVDS DLP DMD
brightness	2400 lm

Connectivity

input sources	VGA (HD15), S-video, Composite Video, Audio (3.5mm), RS232
output sources	VGA (HD15)
control	PC control through RS232

Video Compatibility

computer compatibility	VGA(640x480), SVGA(800x600), XGA(1024x768), SXGA(1280x1024), SXGA+(1400x1050)
video compatibility	NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, SECAM, SDTV(480i/576i), EDTV(480p/756p), HDTV(720p1080i)
aspect ratio	4:3/16:9

Projection

minimum projection distance	1.5 ~ 6m
lens offset	120%
image size	0.75m ~ 6.5m (27” ~ 252")

Power and Consumption

power consumption	285W (typical) / 5W in standby
power supply	100~240Vac, 50/60Hz
lamp	185W / 4000 hours (Eco mode)

Operating Environment

operating temperature	5 – 35°C
audible noise	29dB
brightness uniformity	80%

Weight and Dimensions

product dimensions	225 x 113 x 264mm
product weight	5.3 lbs (2.4 kg)
product color	Black
