InFocus X16 Reference Guide

Maintenance 49
Indicators
Light Status & Description
Power Temp Lamp
Power events
Orange Orange Orange
The projector has just been connected to a power
outlet.
Orange Off Off
Stand-by mode
Green
Flashing
Off Off
Powering up
Green Off Off
Normal operation
Orange
Flashing
Off Off
1. The projector needs 90 seconds to cool down as it
was abnormally shut down without the normal
cooling down process. Or
2. The projector needs to cool for 90 seconds after
the power is turned off.
Orange
Flashing
Off Off
The projector has shutdown automatically. If you try to
re-start the projector, it will shutdown again. Please
contact your dealer for assistance.
Lamp events
Orange
Flashing
Off Red
The projector has shutdown automatically. If you try to
re-start the projector, it will shutdown again. Please
contact your dealer for assistance.
Off Off Red
1. The projector needs 90 seconds to cool down. Or
2. Please contact your dealer for assistance.
Thermal events
Off Red Off
The projector has shutdown automatically. If you try to
re-start the projector, it will shutdown again. Please
contact your dealer for assistance.
Off Red Red
Off Red Green
Off Red Orange
Red Red Red
Red Red Green
Red Red Orange
Green Red Red
Green Red Green
Green Red Orange
Orange Red Red
Orange Red Green
Orange Red Orange
Off Green Red
Off Green Green

InFocus X16 Specifications

Display

native resolution	800 x 600
display technology	0.55” LVDS DLP DMD
brightness	2400 lm

Connectivity

input sources	VGA (HD15), S-video, Composite Video, Audio (3.5mm), RS232
output sources	VGA (HD15)
control	PC control through RS232

Video Compatibility

computer compatibility	VGA(640x480), SVGA(800x600), XGA(1024x768), SXGA(1280x1024), SXGA+(1400x1050)
video compatibility	NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, SECAM, SDTV(480i/576i), EDTV(480p/756p), HDTV(720p1080i)
aspect ratio	4:3/16:9

Projection

minimum projection distance	1.5 ~ 6m
lens offset	120%
image size	0.75m ~ 6.5m (27” ~ 252")

Power and Consumption

power consumption	285W (typical) / 5W in standby
power supply	100~240Vac, 50/60Hz
lamp	185W / 4000 hours (Eco mode)

Operating Environment

operating temperature	5 – 35°C
audible noise	29dB
brightness uniformity	80%

Weight and Dimensions

product dimensions	225 x 113 x 264mm
product weight	5.3 lbs (2.4 kg)
product color	Black
