InFocus X16 Reference Guide

Operation38
Description of each menu
FUNCTION
(default setting/
value)
DESCRIPTION (default setting/value)
Wall Color
(Off)
Corrects the projected picture’s color when the projection
surface is not white. See "Using Wall Color" on page 29 for
details.
Aspect Ratio
(Auto)
There are four options to set the image's aspect ratio
depending on your input signal source. See "Selecting the
aspect ratio" on page 26 for details.
Keystone
(0)
Corrects any keystoning of the image. See "Correcting
keystone" on page 25 for details.
Position
(0)
Displays the position adjustment page. To move the projected
image, use the directional arrow keys. The values shown on the
lower position of the page change with every key press you
made until they reach their maximum or minimum.
Phase
(depends on the
selected input
signal)
Adjusts the clock phase to reduce image
distortion.
H. Size
(0)
Adjusts the horizontal width of the image.
Digital Zoom
(1.0X)
Magnifies or reduces the projected image. See "Magnifying and
searching for details" on page 26 for details.
Preset Mode
(PC source:
Brightest;
Video source:
Standard)
Pre-defined picture modes are provided so you can optimize
your projector image set-up to suit your program type. See
"Selecting a picture mode" on page 28 for details.
Reference
Mode
(Brightest)
Selects a picture mode that most suits your need for the image
quality and further fine-tune the image based on the selections
listed on the same page below. See "Setting the User 1/User 2
mode" on page 29 for details.
Brightness
(50)
Adjusts the brightness of the image. See "Adjusting Brightness"
on page 29 for details.
Contrast
(0)
Adjusts the degree of difference between dark and light in the
image. See "Adjusting Contrast" on page 29 for details.
Color
(0)
Adjusts the color saturation level -- the amount of each color in
a video image. See "Adjusting Color" on page 30 for details.
1. DISPLAY menu
2. PICTURE menu

InFocus X16 Specifications

Display

native resolution	800 x 600
display technology	0.55” LVDS DLP DMD
brightness	2400 lm

Connectivity

input sources	VGA (HD15), S-video, Composite Video, Audio (3.5mm), RS232
output sources	VGA (HD15)
control	PC control through RS232

Video Compatibility

computer compatibility	VGA(640x480), SVGA(800x600), XGA(1024x768), SXGA(1280x1024), SXGA+(1400x1050)
video compatibility	NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, SECAM, SDTV(480i/576i), EDTV(480p/756p), HDTV(720p1080i)
aspect ratio	4:3/16:9

Projection

minimum projection distance	1.5 ~ 6m
lens offset	120%
image size	0.75m ~ 6.5m (27” ~ 252")

Power and Consumption

power consumption	285W (typical) / 5W in standby
power supply	100~240Vac, 50/60Hz
lamp	185W / 4000 hours (Eco mode)

Operating Environment

operating temperature	5 – 35°C
audible noise	29dB
brightness uniformity	80%

Weight and Dimensions

product dimensions	225 x 113 x 264mm
product weight	5.3 lbs (2.4 kg)
product color	Black
