6 . S p e c i f i c a t i o n s
E6 LCD RT
EVOLUTION
5000 (S)
E6 LCD RT
EVOLUTION
6000 (S)
E6 LCD RT
EVOLUTION
8000 (S)
E6 LCD RT
EVOLUTION
10000 (S)
5000 VA 6000 VA 8000 VA 10000 VA
4500 W 5400 W 7200 W 9000 W
4500 W 5400 W 7200 W 9000 W
670 x 440 x 133 (3U) 670 x 440 x 133 (3U) 745 x 440 x 133 (3U) 745 x 440 x 133 (3U)
Dim. D x W x H (mm) - Battery bank 635 x 440 x 133 (3U) 635 x 440 x 133 (3U) 635 x 440 x 133 (3U) 635 x 440 x 133 (3U)
Net weight (kg) : UPS + Battery bank 20 + 59 20 + 59 23,5 + 65 23,5 + 65
670 x 440 x 133 (3U) 670 x 440 x 133 (3U) 745 x 440 x 133 (3U) 745 x 440 x 133 (3U)
20 20 23,5 23,5
110 V*
230 V*
110 V
230 V
110 V
230 V
110 V
230 V
EFFICIENCY
Output outlets IEC standards / programmables
Terminal board
GENERAL CHARACTERISTICS
Technology
On Line Double Conversion
Power (VA)
Power (W)
Standard
Long Backup time (S)
Standard
Dim. D x W x H (mm) - UPS
Long Backup time (S)
Dim. D x W x H (mm) - UPS
Net weight (kg)
Power factor
Standard
Long Backup time (S)
PHYSICAL CHARACTERISTICS
TECHNICAL INPUT CHARACTERISTICS
Low voltage range
Low Line transfer (based on load percentage : 100%-
80% / 80%-70% / 70%-60% / 60%-0%)
-
176 VAC / 154 VAC / 132 VAC / 110 VAC +/- 2%
Low Line comeback
-
186 VAC / 164 VAC / 142 VAC / 120 VAC +/- 2%
0,9
Power factor
0,99 at 100% load
-
290 VAC
Frequency range
50 Hz : 46 Hz ~ 54 Hz ou 60 Hz : 56 Hz ~ 64 Hz
High voltage range
High Line Transfer
-
300 VAC
High Line comeback
Phase
Single phase
Frequency range (Synchronized range)
50 Hz : 46 Hz ~ 54 Hz ou 60 Hz : 56 Hz ~ 64 Hz
Frequency range (Batt mode)
50 Hz +/- 0,1 Hz ou 60 Hz +/- 0,1 Hz
TECHNICAL OUTPUT CHARACTERISTICS
Voltage
200 / 208 / 220 / 230 / 240 VAC
AC voltage regulation (Batt mode)
+/- 1%
Zero
Inverter to Bypass
Zero
Current crest ration
3 : 1 (max)
Harmonic distorsion
<= 2% THD (linear load); <= 4% THD (batt mode before shut down)
Transfer time
Line mode to battery mode
Battery mode
88%
Eco mode
96%
AC mode
90%
Waveform
Pure sinewave
