INFOSEC E6 LCD-RT Evolution - System Single Line Diagram

INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 05 13 AA 59 208 13
7
WARNING: The EPO, RS-232 and USB circuits are IEC 60950 safety extra low voltage (SELV) circuits. This circuit must be
separated from any hazardous voltage circuits by reinforced insulation.
System single line diagram
System single line diagram is demonstrated as picture below:
It’s in closed status for UPS normal operation.
