Terminal User Guide Your Terminal
9
Battery Installation
Your terminal is supplied with a rechargeable battery pack.
In order to access the battery pack you must first remove the battery
access cover by unclipping the catches and lifting the cover as shown.
The battery connector is held into place with a moulded catch. This
catch engages automatically when the connector is pushed into place;
the moulded catch clicks into place (1). You should ensure that
connector is inserted correctly so that the red wire is closest to the side
of your terminal.
To remove the battery pack press the moulded catch in and pull away
the connector (2).
If the terminal displays a battery status icon with a cross in it then a
battery pack is not installed or is installed incorrectly. You will not be
able to perform transactions if there is no battery in the terminal.
The battery pack can only be charged when it is in the terminal by using
either the charger base or the optional travel charger. For maximum
efficiency it is recommended that the battery is always charged at
normal room temperature.
