Terminal User Guide Your Terminal
7
Base Overview
An overview of your terminal’s base unit is shown below:
The connections available on the base are as follows:
Mobile terminals come with a base unit which has charging
capabilities only; the power socket is the only working
connection in this case.
You should set up your base unit in a convenient location close to a
power source and, for Bluetooth terminals, either a telephone socket
and/or an Ethernet socket, as required.
To open the base unit cover, located on the bottom of the base unit, you
must unclip both access clips (as shown above) and lift the cover from
the base unit. To replace the cover reverse these instructions being
sure to engage all the retaining pins before the access clips.
