Innotech MAXIM 1010 User Manual

MAXIM Installation Instructions
Page 12
© Mass Electronics Pty Ltd 2011
Edition 2.0 dated 20/11/2013
1-2 Overview of MAXIM Series Controllers
This section of the manual provides general information for the MAXIM Series Controllers. The
subsequent sections include information on controllers that are installed on the primary network,
and those that are installed on the subsystem network. Information is also provided for the
Subsystem Gateway (IG01). The MAXIM Series controllers are ideal for air conditioning and building
automation, but yet flexible and powerful enough to suit a wide range of other applications.
The MAXIM family of controllers has a wide range of products to suit a broad range of customer
requirements and applications, as illustrated in the table below.
1-2.1 Primary Network Controllers
The controllers that can be installed on the primary network provide communication channels with
Net and Global comms functionality. These controllers can interface with other Innotech network
resources. The MAXIM Series controllers that can be installed on the Innotech primary network are:
• MAXIM II
• MAXIM III
• MAXIM 1010
• MiniMAX (MM01)
MAXIM Controllers MiniMAX MicroMAX VAVMax IG01
I II III 1010 MM01 MM02 UM01 VM01 IG01
Configurable
Universal
Inputs
6 6 20 10 — — — — —
Configurable
Universal
Outputs
— — — 10 — — — — —
Configurable
Universal
Inputs /
Outputs
— — — — 7 7 2 2 —
Digital Relay
Outputs
6 6 12 — — — — — —
Analogue
Outputs
4 4 8 — — — — — —
TRIAC
Outputs
— — -- — 4 4 4 4 –
Thermistor
Input
— — — — — — 1 1 —
Dierential
Pressure
Sensor
— — — — — — — 1 —
Net Comms RS232
   
— — —

Global
Comms
—
   
— — —

Sub Net
Comms
— — — — —
   
Ethernet — — Optional Optional — — — —

Table 1-2: Features of MAXIM Series Controllers
