Innotech MAXIM 1010 - Figure 3-4: MAXIM III Controller Terminal Connection Layout; Figure 3-5: MAXIM 1010 Controller Terminal Connection Layout

Page 27
MAXIM Installation Instructions
© Mass Electronics Pty Ltd 2011
Chapter 3 – Electrical Installation
NET & GLOBAL
COMMS
(RS485)
OPTIONAL
ETHERNET
PORT
ANALOGUE
OUTPUTS
DIGITAL RELAY
OUTPUTS
POWER UNIVERSAL INPUTS
Universal Inputs
Power
Universal Outputs Global &
Net Comms
RS485
Optional
Ethernet
Port
Figure 3-4: MAXIM III controller terminal connection layout
Figure 3-5: MAXIM 1010 controller terminal connection layout
