N2Open (option)
Physical layer and address RS 485 / address: 1…255 / Default: 1
Baud rate 9’600Baud
2 analog outputs (option)
Output signal 4...20mA or 0...20mA
Supply voltage 6...24VDC
Electrical isolation max. 48VDC
Maximum resistance ≤ 837Ω at 24 VDC, 0Ω at 6V
Maximum transformer error 0.15% of measured value + 0.15% of end value
KNX (option)
Type TP1 (2-wire twisted pair), certified according to KNX standard 2.1
Max. power consumption 10mA
Baud rate 9’600Baud
LoRa Wireless (option)
Communication interface LoRaWAN
Frequency band 868MHz (T1 mode) – 16mW
Addresses LoRa address
Max. power consumption 50mA
Impedance of antenna 50Ω
Reinforcement 0db
Antenna connection Connector SMA
Smart Phone Commissioning
Operating system Android >6.0; available on Play Store
App ParamApp
Features
Commissioning and readout via NFC and Bluetooth interface for
better usability
1.1.4 Conformity
CE guidelines
2014/32/EU Measuring Instruments Directive (MID)
2014/30/EU Electromagnetic Compatibility (EMC)
2014/35/EU Low Voltage Directive (LVD)
2012/19/EU Waste Electrical and Electronic Equipment (WEEE)
2011/65/EU Restriction of hazardous substances in electrical and electronic equipment (RoHS)
2014/53/EU Radio Equipment Directive (RED)
Standards
EN 1434
EN 13757-2/3/5/6
EN 61010-1
EN 62368-1
DIN 43863-5
EN 301 489-3:V2.1.1
EN 301 489-17:V3.2.0
EN 61000-3-2
EN 61000-3-3
