Operation
3-140-UM-EN-02
43 / 56
6.6.7 Logger
Display Meaning Visible Editable
Nr Logger number (1…500) Yes Yes for selection
Per Memory interval Yes Service mode
DAT Saving date Yes No
TIM Saving time Yes No
E1 Energy meter reading According to calculator function No
V1 Volume meter reading According to calculator function No
M1 Mass meter reading According to calculator function No
E2
Energy meter reading 2 in op-
tions BDE / BDV
According to calculator function No
V2
Volume meter reading 2 in
options BDE / BDV
According to calculator function No
M2
Mass meter reading 2 in op-
tions BDE / BDV
According to calculator function No
E3
Energy meter reading 3 in op-
tion TGR
According to calculator function No
H1
Auxiliary meters reading 1, in
option Flow
According to calculator function No
H2 Auxiliary meters reading 2 According to calculator function No
Hr Operating Hour counter Yes No
AL Alarms Hour counter Yes No
Err Error hours counter Yes No
DPm Date of maximum period Yes No
TPm Time of maximum period According to calculator function No
Pm Maximum power According to calculator function No
Qvm
Volume flow of TimePoint of
max. power
According to calculator function No
Qmm
Mass flow of TimePoint of
max. power
According to calculator function No
Thm
Temperature hot side of
TimePoint of max. power
According to calculator function No
Tcm
Temperature cold side of
TimePoint of max. power
According to calculator function No
6.6.8 Inputs
Display Meaning Visible Editable
Nr Input number (1…2) Yes Yes for selection
Fct Function Yes No
ImP
Pulse value of the input
pulses
According to calculator function Programming mode
Sid
Installation side of the flow
meter
According to calculator function Programming mode
MAX Maximum input frequency According to calculator function Programming mode
STA Actual status Yes No
MAX Upper limit for th / tc alarm Yes No
MIN Lower limit for th / tc alarm Yes No
