Operation
3-140-UM-EN-02
47 / 56
Display Meaning Visible Editable
dtc
Automatic sensor adjust-
ment
Yes Programming mode
6.6.20 System
Display Meaning Visible Editable
FNr Serial number Yes No
SYS Calculator function Yes No
DAT Manufacturing date Yes No
RW
Firmware version of calcula-
tor
Yes No
FW
Firmware version of main
board
Yes No
HW Hardware version Yes No
CS Checksum of firmware Yes No
6.6.21 Init
One-time on-site setting of the calibration-relevant input values “IMP EBS“
u Assure that with the selected unit the accumulative energy amount can be handled without counter
overflow.
This mode can be set once on site (activation by zeroing the pulse value).
Display Meaning Visible Editable
Init
Allows the one-time setting
of the values ImP / Sid / Eu /
Ed / V during commissioning
on site
Editable only in edit mode Init
Go
Confirms the one-time set-
ting at commissioning
Editable only in edit mode Go
6.7 Commissioning
Depending on the required data output and the installed communication modules, a number of parameters
have to be set.
The adjustable values are assigned to three safety levels:
Safety level Access Level Code
User mode
When the housing is closed the freely accessible data can be
displayed by using the keys.
Service mode
Can be activated with the service key while the cover is open.
Allows the setting of all parameters that are not required to
be calibrated for commissioning and the display of all set-
tings.
1111
Programming
mode
Complete parameterization, including calibration-relevant
values. Can only be activated by destroying the calibration
seal. Not described in this manual.
3132
u Select the service mode [}p.40].
u Select the menu for the required data output [}p.39].
u Set the required parameters [}p.39].
