INTEGRA Metering CALEC ST III User Manual

Operation
3-140-UM-EN-02
45 / 56
Display Meaning Visible Editable
M
Number of decimal places for
mass unit
Yes Programming mode
P Power unit Yes Service mode
Q Volume flow unit Yes Service mode
T Temperature unit Yes Service mode
EP
Pulse value for energy pulse
output
Yes Service mode
VP
Pulse value for volume pulse
output
Yes Service mode
MP Pulse value for mass unit Yes Service mode
6.6.12 M-Bus
Display Meaning Visible Editable
Nr M-Bus number (1…5) Yes Yes for selection
Adr Primary M-Bus address Yes Service mode
SEK Secondary M-Bus address Yes Service mode
BAU Baud rate Yes Service mode
Acc Meter reading prompt Yes Yes
APP M-Bus application reset Yes Service mode
6.6.13 Modbus
This menu is only available if the Modbus hardware module is installed in the device.
Display Meaning Visible Editable
Nr Number of Modbus Yes Yes for selection
Adr Address of Modbus Yes Service mode
BAU Baud rate Yes Service mode
Par Parity Yes Service mode
Trm
Turn termination resistor
on / off
Yes Service mode
6.6.14 N2-Bus
This menu is only available if the N2Open hardware module is installed in the device.
Display Meaning Visible Editable
Nr Number of N2Open Yes Yes
Adr Address of N2Open Yes Service mode
TRM
Turn termination resistor
on / off
Yes Service mode
6.6.15 BACnet
This menu is only available if the BACnet hardware module is installed in the device.
Display Meaning Visible Editable
Nr Number of BACnet Yes Yes
Adr Address of BACnet Yes Service mode
Mod Mode (master / slave) Yes Service mode
DIN
BAcnet device instance num-
ber
Yes Service mode
