6.6 Menu structure
6.6.1 Counter
The depiction of fields in the menu structure depends on the respective options.
Display Meaning Visible Editable
E1 Energy meter reading According to calculator function Programming mode
V1 Volume meter reading According to calculator function Programming mode
M1
Mass meter reading (op-
tional)
According to calculator function Programming mode
E2
Energy meter 2 reading (op-
tional BDE/TGR)
According to calculator function Programming mode
V2
Volume meter 2 reading (op-
tional BDE)
According to calculator function Programming mode
M2 Mass meter 2 reading According to calculator function Programming mode
E3
Energy meter 3 reading (op-
tional TGR)
According to calculator function Programming mode
H1
Auxiliary counter 1 reading
(optional flow)
According to calculator function Service mode
H2 Auxiliary counter 2 reading According to calculator function Service mode
Imp Pulse value of flow meter According to calculator function No
Sid
Installation side of flow me-
ter
According to calculator function No
6.6.2 Info
This menu is only visible if an error is present. It displays the type of error as described in the table.
Display Meaning
SYSt-Err Error system
U-Err Error supply
th-Error Error temperature sensor hot side
tc-Error Error temperature sensor cold side
MEM-Err Error of internal memory EEPROM
OPT-Err Error on one of the option modules (HW)
th-ALArM Temperature on hot side outside the permitted range
tc-ALArM Temperature on cold side outside the permitted range
dt-ALArM Temperature difference outside the permitted range
Ext-AL External alarm
AP-Err Communication problem between main board and calculator
SEAL-Err MID seal broken
6.6.3 Test
This menu is available for LCD test purposes.
6.6.4 Instant
Display Meaning Visible Editable
Th
Current temperature hot side
(for cooling = return flow)
According to calculator function No
Tc
Current temperature cold
side (for cooling = forward
flow)
According to calculator function No
