INTEGRA Metering CALEC ST III User Manual

Introduction
3-140-UM-EN-02
9 / 56
Additional functions
Heat- / cold meters eight tariffs
This option allows the management of up to eight different tariffs
with reference temperature control. The measurement is split into
different registers.
Data backup in the event of a
power failure
In EERPOM >10 years
Adjustable low temperature differ-
ence ΔT cut-off (LFCO)
Function for stopping the energy calculation when the temperature
difference is too low, ΔT LFCO adjustable ΔT = 0-2.99K.
Limit value monitoring
One-sided or two-sided, hysteresis 0 – 10%, action of the output
signal is selectable.
Mains version
Power supply (Standard version) 1W / 24VAC/DC – 240VAC, 50/60Hz (according to EN 1434).
Power supply (Smart version) 5W/110 – 240VAC, 50/60Hz (according to EN 1434)
Calculation cycle 1s
Backup battery real-time clock 3V Li-Mn CR1220
Low voltage power supply for flow meters
Voltage Flow meter
Supply voltage (Standard & Smart
version)
2x 3.6VDC, max. 2mA
galvanic isolation max. 48VDC
e.g. AMFLO® SONIC UFA 113
Supply voltage (only on Smart ver-
sion)
1x 24VDC, max.150mA
galvanic isolation max.48V DC
e.g. AMFLO® MAG Smart or ac-
tive sensors
3.6V sensor power output
Power supply, galvanically isolated to the system, for external flow
meters.
V
out nom
3.6V
V
OUT min
3.45V
V
OUT max
3.75V
I
Out min
10mA
V
Ripple
50mV
Load regulation ±1% @load steps of 5mA
Insulation voltage galvanic isola-
tion
Normative 48V
technical: 312VAC
Clearance to other circuits 0.5mm
24V sensor power output
Power supply, galvanically isolated to the system, for external loads
or flow meters.
V
out nom
24V
V
OUT min
22V
V
OUT max
26V
I
Out min
180mA
V
Ripple
200mV
Load regulation ±6% @load steps of 100mA
Insulation voltage galvanic isola-
tion
Normative 48V
Technical: 312VAC
Clearance to other circuits 0.5mm
Pulse inputs
Input #1 (10/11)
Input #2 (54/55)
Connecting a pulse generator according to NAMUR, with potential-
free contact (reed relay) or SSR (solid state relay), or for active sen-
sors with the following values.
