76
En
Controlling Zone 2 with the Remote
Controller
Note
To control Zone 2, you must press the remote controller’s
Zone2 first.
Zone2 turns red while Zone 2 is on.
Note
Only analog input sources are output by the ZONE 2 PRE OUT
and FRONT WIDE/ZONE 2 L/R terminals. Digital input
sources are not output. If no sound is heard when an input source
is selected, check if it’s connected to an analog input.
You cannot select different AM or FM radio stations for your
main room and Zone 2. The same AM/FM radio station will be
heard in each room. For example, if you have an FM station for
the main room, that station will also be used in Zone 2.
When you connect Zone 2 speakers directly to the AV controller,
listening modes that require surround back speakers or front high
speakers or front wide speakers (6.1/7.1), such as Dolby Digital
EX, DTS-ES, THX Ultra2 Cinema, Dolby Pro Logic IIz Height,
and Audyssey DSX™ are unavailable.
When the input selector of Zone 2 is selected, power consump-
tion on standby mode slightly increases.
While Zone 2 is on, u functions will not work.
Adjusting the Volume for Zone 2
Muting Zone 2
Adjusting the Tone and Balance of Zone 2
Note
Zone 2 can also be unmuted by adjusting the volume.
The Zone 2 volume, tone, and balance function have no effect on
ZONE 2 PRE OUT when the “Zone 2 Out” setting is set to
Fixed” ( 75).
1
Press Zone2, then point the remote controller at
the AV controller and press On.
Tip
•The 12V TRIGGER OUT goes high (+12 V).
2
To select an input source for Zone 2, press Zone2,
followed by Input Selector.
To select AM or FM, press Tuner input selector and
Zone2.
You can also select SIRIUS.
3
To turn off Zone 2, press Zone2, followed by
Standby.
Zone2
Standby
On
Input
Selector
On the remote controller, press Zone2, and then
use VOL q/w.
On the AV controller, press Zone 2 Level Up q/
Down w.
On the remote controller, press Zone2, and then
press Muting.
To unmute a zone, on the remote controller, press
Zone2, and then press Muting again.
1
On the AV controller, press Zone 2.
2
Press the AV controller’s Tone to select “Bass”,
“Treble” or “Balance”.
3
Use –/+ to adjust the bass, treble or balance.
You can boost or cut the bass or treble from –10 dB
to +10 dB in 2 dB steps.
You can adjust the balance from 0 in the center to
+10 dB to the right or +10 dB to the left in 2 dB
steps.
