Intel Agilex User Guide

2.1.7. Accumulator, Chainout Adder, and Preload Constant for Fixed-Point
Arithmetic
The Intel Agilex variable precision DSP block supports accumulator and adder up to 64
bits for fixed-point arithmetic.
The following signals can dynamically control the function of the accumulator and the
chainout adder:
•
NEGATE
•
LOADCONST
•
ACCUMULATE
•
DISABLE_CHAINOUT
The accumulator and chainout adder features are not available in two fixed-point
arithmetic independent 18 x 19 modes.
Table 7. Accumulator Functions and Dynamic Control Signals
Function Description NEGATE LOADCONST ACCUMULATE
Zeroing Disables the accumulator. 0 0 0
Preload
The result is always added to the preload
value. Only one bit of the 64-bit preload
value can be “1”. You can use this function
to round the DSP result to any position of
the 64-bit result.
0 1 0
Accumulation
Adds the current result to the previous
accumulate result.
0 X 1
Decimation +
Accumulation
This function takes the current result,
converts it into two’s complement, and
adds it to the previous result.
1 X 1
Decimation +
Chainout Adder
This function takes the current result,
converts it into two’s complement, and
adds it to the output of previous DSP
block.
1 0 0
2.1.7.1. Dynamic Chainout
Intel Agilex devices support CHAINOUT port which can be dynamically disabled or
enabled. In this feature, the input register is always enabled for the
DISABLE_CHAINOUT signal.
2. Intel Agilex Variable Precision DSP Blocks Architecture
UG-20213 | 2019.04.02
Intel
®
Agilex
™
Variable Precision DSP Blocks User Guide
Send Feedback
18
