Intel Agilex User Guide

If the double accumulation register is enabled, an extra clock cycle delay is added into
the feedback path of the accumulator.
This register has the same settings as the output register bank.
By enabling this register, you can have two accumulator channels using the same
number of variable precision DSP block. This is useful when processing interleaved
complex data (I, Q).
2.1.10. Output Register Bank for Fixed-Point Arithmetic
The positive edge of the clock signal triggers the 74-bit bypassable output register
bank and is cleared after power up.
The following variable precision DSP block signals control the output register per
variable precision DSP block:
•
CLK
•
ENA[2..0]
•
CLR[1]
Related Information
Configurations for Input, Pipeline, and Output Registers on page 62
Provides information about restrictions on fixed-point arithmetic output registers.
2.2. Floating-Point Arithmetic
2.2.1. Input Register Bank for Floating-Point Arithmetic
The input register banks for floating-point DSP blocks are available for the following
input signals:
•
fp32_adder_a
•
fp32_adder_b
•
fp32_mult_a
•
fp32_mult_b
•
fp16_mult_top_a
•
fp16_mult_top_b
•
fp16_mult_bot_a
•
fp16_mult_bot_b
• Dynamic ACCUMULATE control signal
2. Intel Agilex Variable Precision DSP Blocks Architecture
UG-20213 | 2019.04.02
Intel
®
Agilex
™
Variable Precision DSP Blocks User Guide
Send Feedback
20
