10. Click Start.
11. After the flash writing process has completed, power cycle the board and look for
the MAX CONF DONE LED to turn ON if successful.
12. Altera recommends that you return to the MAX V System Controller factory design
after completing the flash writing. To do so, program the MAX V with
cycloneVSX_5csxfc6df31_soc\factory_recovery\max<version>.pof. For
more information, refer to the Restoring the MAX V CPLD to the Factory Settings
section.
Note: The flash writer version blinks the SEL 2, 1, and 0 LEDs and does not
support the Power Monitor, Clock Control, or other logic functions. Use the
flash writer only for flash programming.
To ensure that you have the most up-to-date factory restore files and information
about this product, refer to the Cyclone V SoC Development Kit webpage of the Intel
website.
Related Information
• Restoring the MAX V CPLD to the Factory Setting on page 22
• Cyclone V SoC Development Kit Website
