4. Board Update Portal
The Board Update Portal web page provides links to useful information on the Intel
website. You can use this web page to interact with your board:
• Blinking LEDs
• Writing text messages to the LCD
• Mouse over the board photo to view features
The Board Update Portal web page is served by the web server application running on
the HPS on your board.
4.1. Connecting to the Board Update Portal Web Page
Ensure that you have the following setup or installed:
• A PC with a connection to a working Ethernet port on a DHCP enabled network.
• A separate working Ethernet port connected to the same network for the board.
• The Ethernet and power cables that are included in the kit.
To connect to the Board Update Portal web page, perform these steps:
1. Keep the CSEL and BSEL jumpers and the DIP switch SW2.3 in the factory default
positions.
2. Change J26 as Short1-2 and set SW as follows:
• SW1: ALL OFF
• SW2: ALL OFF
• SW3: ON-OFF-ON-OFF-ON-ON
• SW4: OFF-OFF-ON-ON
3. Download image to SD card and insert SD card to J3.
4. Connect J8 to your computer and power up the board.
5. Install the USB virtual COM port drivers to access the Linux system through a
terminal window.
6.
Type ifconfig to get the IP address as root.
For more information, refer to the Cyclone V SOC GSRD page on
RocketBoards.org.
