To convert the files, follow these steps:
1. On the File menu, click Convert Programming Files.
2. For Programming file type, specify Programmer Object File (.pof) and name
the file.
3. For Configuration device, select CFI_512Mb for this kit's CFI device.
4. To add the configuration data, under Input files to convert, select SOF Data.
5.
Click Add File and browse to the .sof files you want to add.
If you want to store the data from other .sof files in a different page, click Add
SOF page. Add the .sof files to the new page
6. Select SOF Data and click Properties to set the page number and name.
7. Under Address mode for selected pages, choose the User Hardware 1 offset as
listed in the memory map in the Byte Address Flash Memory Map table in the
Appendix—CFI Flash Memory Map section as 0x006E.0000.
Related Information
• Factory Default Switch and Jumper Settings on page 15
• CFI Flash Memory Map on page 47
A.2.2. quad SPI Flash Memory
A.2.2.1. Programming quad SPI Flash Using the Quartus Prime Programmer
Although the quad SPI flash is not programmed by factory default, you can program
this device using quartus_hps.exe that resides in the quartus/bin directory.
1. To use this tool, open a command window and change directories to your 22.1std
or later installation (for example, c:\intelFPGA\22.1std\quartus\bin).
2. To program an entire file to quad SPI flash starting at address 0, type the
following command:
quartus_hps.exe -c <programming cable index> -o P <flash_boot_image.bin>
3. For a typical setup, where the Cyclone V SoC board is the only board connected to
the PC, you can detect the quad SPI flash. To do so, run the following command:
quartus_hps.exe -o 1 -c1 <enter>
4. Using this tool requires that the board be placed into quad SPI boot mode. To do,
set BOOTSEL1 (J29) shunt to the 1-2 position. The default position is 2-3 (SD
card). You must power cycle the board after changing this jumper for the settings
to take effect.
5. For help and more options, type the following command:
quartus_hps.exe --help
For more information, refer to the SoC Board QSPI Boot page on RocketBoards.org.
Related Information
SoC Board QSPI Boot, RocketBoard.org
