116 Datasheet

Intel

Celeron

Processor up to 1.10 GHz

Figure 39. Side View Airspace Requirements for the Boxed Intel

Celeron

Processor in the

FC-PGA/FC-PGA2 and PPGA Packages

Figure 40. Volumetric Keepout Requirements for The Boxed Fan Heatsink

Measure ambient temperature 0.3"

above center of fan inlet

0.20 Min

Air Space

0.20 Min

Air Space

Fan Heatsink

Processor
