72 Datasheet
Intel
®
Celeron
®
Processor up to 1.10 GHz
A72 D3# AGTL+ I/O
A73 D1# AGTL+ I/O
A74 V
SS Power/Other
A75 BCLK System Bus Clock Input
A76 Reserved
Reserved for Pentium
II
processor
A77 Reserved
Reserved for Pentium
II
processor
A78 V
SS Power/Other
A79 Reserved
Reserved for Pentium
II
processor
A80 Reserved
Reserved for Pentium
II
processor
A81 A30# AGTL+ I/O
A82 V
SS Power/Other
A83 A31# AGTL+ I/O
A84 A27# AGTL+ I/O
A85 A22# AGTL+ I/O
A86 V
SS Power/Other
A87 A23# AGTL+ I/O
A88 Reserved Reserved for Future Use
A89 A19# AGTL+ I/O
A90 V
SS Power/Other
A91 A18# AGTL+ I/O
A92 A16# AGTL+ I/O
A93 A13# AGTL+ I/O
A94 V
SS Power/Other
A95 A14# AGTL+ I/O
A96 A10# AGTL+ I/O
A97 A5# AGTL+ I/O
A98 V
SS Power/Other
A99 A9# AGTL+ I/O
A100 A4# AGTL+ I/O
A101 BNR# AGTL+ I/O
A102 V
SS Power/Other
A103 BPRI# AGTL+ Input
A104 TRDY# AGTL+ Input
A105 DEFER# AGTL+ Input
A106 V
SS Power/Other
Table 45. S.E.P. Package Signal Listing
by Pin Number
Pin
No. Pin Name Signal Buffer Type
A107 REQ2# AGTL+ I/O
A108 REQ3# AGTL+ I/O
A109 HITM# AGTL+ I/O
A110 V
SS Power/Other
A111 DBSY# AGTL+ I/O
A112 RS1# AGTL+ Input
A113 Reserved Reserved for Future Use
A114 V
SS Power/Other
A115 ADS# AGTL+ I/O
A116 Reserved Reserved for Future Use
A117 Reserved
Reserved for Pentium
II
processor
A118 V
SS Power/Other
A119 VID2 Power/Other
A120 VID1 Power/Other
A121 VID4 Power/Other
B1 EMI Power/Other
B2 FLUSH# CMOS Input
B3 SMI# CMOS Input
B4 INIT# CMOS Input
B5 V
TT Power/Other
B6 STPCLK# CMOS Input
B7 TCK TAP Input
B8 SLP# CMOS Input
B9 V
TT Power/Other
B10 TMS TAP Input
B13 V
CC
CORE
Power/Other
B14 THERMDP Power/Other
B15 THERMDN Power/Other
B16 LINT1/NMI CMOS Input
B17 V
CC
CORE
Power/Other
B18 PICCLK APIC Clock Input
B19 BP2# AGTL+ I/O
B20 Reserved Reserved for Future Use
B21 BSEL Power/Other
B22 PICD1 APIC I/O
B23 PRDY# AGTL+ Output
B24 BPM1# AGTL+ I/O
Table 45. S.E.P. Package Signal Listing
by Pin Number
Pin
No. Pin Name Signal Buffer Type
