Intel CELERON 1.10 GHZ User Manual

82 Datasheet
Intel
®
Celeron
®
Processor up to 1.10 GHz
Table 49. PPGA Package Signal Listing
by Pin Number
Pin
No. Pin Name Signal Buffer Type
A3 D29# AGTL+ I/O
A5 D28# AGTL+ I/O
A7 D43# AGTL+ I/O
A9 D37# AGTL+ I/O
A11 D44# AGTL+ I/O
A13 D51# AGTL+ I/O
A15 D47# AGTL+ I/O
A17 D48# AGTL+ I/O
A19 D57# AGTL+ I/O
A21 D46# AGTL+ I/O
A23 D53# AGTL+ I/O
A25 D60# AGTL+ I/O
A27 D61# AGTL+ I/O
A29 Reserved Reserved for Future Use
A31 Reserved Reserved for Future Use
A33 Reserved Reserved for Future Use
A35 PRDY# AGTL+ Output
A37 V
SS Power/Other
AA1 A27# AGTL+ I/O
AA3 A30# AGTL+ I/O
AA5 V
CC
CORE
Power/Other
AA33 Reserved Reserved for Future Use
AA35 Reserved Reserved for Future Use
AA37 V
CC
CORE
Power/Other
AB2 V
CC
CORE
Power/Other
AB4 A24# AGTL+ I/O
AB6 A23# AGTL+ I/O
AB32 V
SS Power/Other
AB34 V
CC
CORE
Power/Other
AB36 V
CC
CMOS
Power/Other
AC1 Reserved Reserved for Future Use
AC3 A20# AGTL+ I/O
AC5 V
SS Power/Other
AC33 V
SS Power/Other
AC35 FERR# CMOS Output
AC37 Reserved Reserved for Future Use
AD2 V
SS Power/Other
AD4 A31# AGTL+ I/O
AD6 V
REF
5
Power/Other
AD32 V
CC
CORE
Power/Other
AD34 V
SS Power/Other
AD36 V
CC
1.5
Power/Other
AE1 A17# AGTL+ I/O
AE3 A22# AGTL+ I/O
AE5 V
CC
CORE
Power/Other
AE33 A20M# CMOS Input
AE35 IERR# CMOS Output
AE37 FLUSH# CMOS Input
AF2 V
CC
CORE
Power/Other
AF4 Reserved Reserved for Future Use
AF6 A25# AGTL+ I/O
AF32 V
SS Power/Other
AF34 V
CC
CORE
Power/Other
AF36 V
SS Power/Other
AG1 EDGCTRL Power/Other
AG3 A19# AGTL+ I/O
AG5 V
SS Power/Other
AG33 INIT# CMOS Input
AG35 STPCLK# CMOS Input
AG37 IGNNE# CMOS Input
AH2 V
SS Power/Other
AH4 Reserved Reserved for Future Use
AH6 A10# AGTL+ I/O
AH8 A5# AGTL+ I/O
AH10 A8# AGTL+ I/O
AH12 A4# AGTL+ I/O
AH14 BNR# AGTL+ I/O
AH16 REQ1# AGTL+ I/O
AH18 REQ2# AGTL+ I/O
AH20 Reserved Reserved for Future Use
AH22 RS1# AGTL+ Input
AH24 V
CC
CORE
Power/Other
AH26 RS0# AGTL+ Input
AH28 THERMTRIP# CMOS Output
AH30 SLP# CMOS Input
Table 49. PPGA Package Signal Listing
by Pin Number
Pin
No. Pin Name Signal Buffer Type
