Intel CELERON 1.10 GHZ - Page 91

Datasheet 91
Intel
®
Celeron
®
Processor up to 1.10 GHz
VSS P32 Power/Other
V
SS P36 Power/Other
V
SS Q5 Power/Other
V
SS R34 Power/Other
V
SS T32 Power/Other
V
SS T36 Power/Other
V
SS U5 Power/Other
V
SS V2 Power/Other
V
SS A37 Power/Other
V
SS AB32 Power/Other
V
SS AC33 Power/Other
V
SS AC5 Power/Other
V
SS AD2 Power/Other
V
SS AD34 Power/Other
V
SS AF32 Power/Other
V
SS AF36 Power/Other
V
SS AG5 Power/Other
V
SS AH2 Power/Other
V
SS AH34 Power/Other
V
SS AJ11 Power/Other
V
SS AJ15 Power/Other
V
SS AJ19 Power/Other
V
SS AJ23 Power/Other
V
SS AJ27 Power/Other
V
SS AJ3 Power/Other
Table 50. PPGA Package Signal Listing
in Order by Signal Name
Pin Name
Pin
No. Signal Buffer Type
VSS AJ7 Power/Other
V
SS AK36 Power/Other
V
SS AK4 Power/Other
V
SS AL1 Power/Other
V
SS AL3 Power/Other
V
SS AM10 Power/Other
V
SS AM14 Power/Other
V
SS AM18 Power/Other
V
SS AM2 Power/Other
V
SS AM22 Power/Other
V
SS AM26 Power/Other
V
SS AM30 Power/Other
V
SS AM34 Power/Other
V
SS AM6 Power/Other
V
SS AN3 Power/Other
V
SS B12 Power/Other
V
SS V34 Power/Other
V
SS X32 Power/Other
V
SS X36 Power/Other
V
SS Y37 Power/Other
V
SS Y5 Power/Other
V
SS Z2 Power/Other
V
SS Z34 Power/Other
V
SS AJ31 Power/Other
V
SS Y33 Power/Other
Table 50. PPGA Package Signal Listing
in Order by Signal Name
Pin Name
Pin
No. Signal Buffer Type
