Intel E810 VDA4T Series User Manual

646265-004 51
Intel
®
Ethernet Network Adapter E810-XXVDA4T
User Guide
NIC1 Linux software stack:
NIC1 configuration:
1. Run one instance of ptp4l per E810-XXVDA4T:
# ptp4l -m -f config.cfg -i ens1f0 -i ens1f1 -i ens1f2 -i ens1f3
2. Run phc2sys to synchronize system time to the PHC time:
# phc2sys -s ens1f0 -c CLOCK_REALTIME -w -m
Figure 13. External Connections: Two E810-XXVDA4T without GNSS Linux Software Stack
Figure 14. External Connections: Two E810-XXVDA4T without GNSS NIC1 Software Stack
NIC1
ptp4l
phc2sys
System Clock
PHC1
Network
phc_ctl
ptp4l
NIC2
PHC2
NIC
ptp4l
phc2sys
System Clock
PHC1
Tx/Rx Timestamps
Network
