Intel
®
Ethernet Network Adapter E810-XXVDA4T
User Guide
52 646265-004
NIC2 Linux software stack:
NIC2 configuration:
1. Run one instance of ptp4l per E810-XXVDA4T:
# ptp4l -m -f config.cfg -i ens2f0 -i ens2f1 -i ens2f2 -i ens2f3
2. Monitor PHC time on adapter two vs. system time:
# phc_ctl ens2f0 cmp
Figure 15. External Connections: Two E810-XXVDA4T without GNSS NIC1 Software Stack
NIC
ptp4l
phc_ctl
System Clock
Tx/Rx Timestamps
Network
PHC2
