Intel NUC5PGYH Technical Product Specification

Intel NUC Board NUC5PGYH Technical Product Specification
12
Table 1. Feature Summary (continued)
Expansion Capabilities
One M.2 Module supporting M.2 2230 cards (key type E)
BIOS
•
Intel
®
BIOS resident in the Serial Peripheral Interface (SPI) Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play, and
System Management BIOS (SMBIOS)
LAN Support
Gigabit (10/100/1000 Mb/s) LAN subsystem using the Realtek* 8111HN Gigabit Ethernet
Controller
Hardware Monitor
Subsystem
Hardware monitoring subsystem, based on an ITE IT8607D embedded controller, including:
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• One processor fan header
• Fan sense input used to monitor fan activity
• Simple fan speed control
Wireless
•
Intel® Dual Band Wireless-AC 3165 module
• 2nd Gen 802.11ac, Dual Band, 1x1 Wi-Fi + Dual Mode Bluetooth* 4.0
• Maximum Transfer speed up to 433Mbps
• Supports Intel® Wireless Display (WiDi)
• Supports Intel® Smart Connect Technology
• Pre-installed in M.2 2230 slot

Intel NUC5PGYH Specifications

General

Status	Discontinued
BIOS type	EEPROM
Product type	Mini PC
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	UCFF
Removable memory card slot	SDXC with UHS-I support
Supported RAID configuration	N/A
Trusted Platform Module (TPM)	No
HDD size	2.5 \
Storage media	Flash
Card reader integrated	Yes
Total storage capacity	32 GB
Compatible memory cards	SDXC
Embedded storage capacity	32768 MB
Number of storage drives installed	1
Power supply	65 W
DC input voltage	12 - 19 V
Power supply input voltage	19 V
Bus type	DMI
Stepping	C0
Tjunction	90 °C
Product family	Intel NUC
Product series	Intel NUC kit
Processor cache	2 MB
Processor cores	4
Processor model	N3700
System bus rate	2.5 GT/s
Processor family	Intel Pentium N
Processor series	Intel® Pentium N3000 Series for Mobile
Processor socket	BGA 1170
Product codename	Grass Canyon
Processor codename	Braswell
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.4 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2, 1x4, 2x2, 2x1, 4x1
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
Memory types supported by processor	DDR3L-SDRAM
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	12.8 GB/s
Maximum internal memory supported by processor	8 GB
Processor code	SR29E
Processor ARK ID	87261
Processor package size	25 x 27 mm
Intel Smart Connect Technology version	0.00
Intel Identity Protection Technology version	1.00
Chassis type	Nettop
Product color	Black, Silver
Cable lock slot type	Kensington
Number of execution units	16
Discrete graphics card model	Not available
Number of displays supported	2
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	400 MHz
On-board graphics card dynamic frequency (max)	700 MHz
Number of displays supported (on-board graphics)	3
ARK ID	88065
Form factor	UCFF (4\
Audio channels	7.1
Graphics output	VGA (HDB15); HDMI 1.4b
Additional headers	2x USB2.0, AUX_PWR
USB ports quantity	6
Maximum internal memory	8192 MB
Optical drives quantity	0
Export Control Classification Number (ECCN)	5A992C
Intel® Virtualization Technology (Intel® VT)	VT-x, VT-d
Commodity Classification Automated Tracking System (CCATS)	G157815L2
Memory slots	1x SO-DIMM
Internal memory	2 GB
Memory channels	Single-channel
Memory layout (slots x size)	1 x 2 GB
Operating system installed	Windows 10
Pre-installed operating system	Windows 10, 64-bit*
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
HDMI version	1.4b
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
M.2 card slot (wireless)	2230 (E-key)
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 3165
Ethernet LAN data rates	10, 1000, 100 Mbit/s
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	-20 - 70 %
Sustainability certificates	RoHS
Certification	IEC, UL, EN, CAN/CSA-C22.2, CISPR 22, FCC, ICES-003, EN, VCCI V3, KN, CNS, WEEE
Processor included	Intel® Pentium® Processor N3700 (2M Cache, up to 2.40 GHz)
Market segment	Desktop
Last change	63903513
Built-in WiFi	Intel Wireless-AC 3165 + Bluetooth 4.2
Supported storage drives form factor (internal)	2.5\
Harmonized System (HS) code	8471500150
