Intel NUC5PGYH

iii
Board Identification Information
Basic Intel
®
NUC Board NUC5PGYH Identification Information
AA Revision
BIOS Revision
Notes
H78168-100
PYBSWCEL.86A
1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. Intel
®
Pentium
®
processor N3700, used on this AA revision, consists of the following component:
Device
Stepping
S-Spec Numbers
Intel Pentium processor N3700 C0 SR29E
Specification Changes or Clarifications
The table below indicates the Specification Changes or Specification Clarifications that apply to
the Intel NUC Board NUC5PGYH.
Specification Changes or Clarifications
Date
Type of Change
Description of Changes or Clarifications
October 2015
Spec Clarification
Removed all reference to the Front Panel Header as it was not stuffed on the
board.
November 2015
Spec Clarification
Updated the operating temperature in Table 22. Environmental
Specifications.
March 2016
Spec Clarification
Added a Note to Section 2.2.4.4 to clarify what the Auxiliary Power Connector
is used for.
May 2016 Spec Change
•
Deleted the Near Field Communication (NFC) header and all related text.
• Added Section 2.2.4.5 Front Panel Header (2.0 mm Pitch).
June 2016 Spec Clarification
•
Update SATA speed to 6.0 Gb/s.
August 2016 Spec Change
• Added 1.5.1.4 Analog Display (VGA)
• Added information to section 1.5.1.1 Intel® High Definition (Intel® HD)
Graphics
• In Section 1.11.1 Hardware Monitoring, changed info to ITE IT8607D
October 2016
Spec Change
• Added information about supported 8 GB to 128 GB SD Card Sizes to
SDXC Card Reader section
Errata
Current characterized errata, if any, are documented in a separate Specification Update. See
http://www.intel.com/content/www/us/en/nuc/overview.html
for the latest documentation.
