1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the board.
Table 1. Feature Summary
4.0 inches by 4.0 inches (101.60 millimeters by 101.60 millimeters)
Processor
•
Soldered-down quad-core Intel
®
®
processor N3700 with up to 6 W TDP
― Integrated graphics
― Integrated memory controller
• 2 GB DDR3L 1600 MHz SO-DIMM pre-installed
• Support for 1066 MHz/1666 MHz memory speeds
Note: If you install 1333 MHz, it will run at 1066 MHz.
• Support for up to 8 GB of system memory with one SO-DIMM using 4 Gb memory
technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory
• Integrated graphics support with Intel
®
Graphics Technology:
― High Definition Multimedia Interface* (HDMI*)
• Intel® High Definition (Intel
®
HD) Audio via the HDMI v1.4b interface through the
processor
• Realtek HD Audio via a stereo microphone/headphone 3.5 mm jack on the front panel
• Compressed 5.1/7.1 digital audio through a Mini-TOSLINK jack on the back panel
Peripheral Interfaces
•
― Two ports are implemented with external front panel connectors (one blue and one
orange charging capable)
― Two ports are implemented with external back panel connectors (blue)
• USB 2.0 ports:
― Two ports via one dual-port internal 1x8 1.25 mm pitch header (white)
― One port is reserved for an M.2 2230 for the Wireless module
• Consumer Infrared (CIR)
• One SATA 6.0 Gb/s port (black)
- Supports one 2.5“ SSD or HDD up to 9.5mm
• One full sized SDXC slot
• 32 GB Embedded MultiMediaCard (e·MMC) onboard storage module
continued
