Intel NUC5PGYH Technical Product Specification

Regulatory Compliance and Battery Disposal Information
69
Portuguese Este produto cumpre com as normas da Diretiva Européia 2004/108/EC, 2006/95/EC
& 2002/95/EC.
Español Este producto cumple con las normas del Directivo Europeo 2004/108/EC, 2006/95/EC
& 2002/95/EC.
Slovensky Tento produkt je v súlade s ustanoveniami európskych direktív 2004/108/EC,
2006/95/EC a 2002/95/EC.
Slovenščina Izdelek je skladen z določbami evropskih direktiv 2004/108/EC, 2006/95/EC in
2002/95/EC.
Svenska Denna produkt har tillverkats i enlighet med EG-direktiv 2004/108/EC, 2006/95/EC &
2002/95/EC.
Türkçe Bu ürün, Avrupa Birliği’nin 2004/108/EC, 2006/95/EC ve 2002/95/EC yönergelerine uyar.
5.1.3 Product Ecology Statements
The following information is provided to address worldwide product ecology concerns and
regulations.
5.1.3.1 Disposal Considerations
This product contains the following materials that may be regulated upon disposal: lead solder
on the printed wiring board assembly.
5.1.4 EMC Regulations
Intel NUC Board NUC5PGYH complies with the EMC regulations stated in Table 32 when correctly
installed in a compatible host system.
Table 32. EMC Regulations
Regulation
Title
FCC 47 CFR Part 15, Subpart B
Title 47 of the Code of Federal Regulations, Part 15, Subpart B, Radio Frequency
Devices. (USA)
ICES-003 Interference-Causing Equipment Standard, Digital Apparatus. (Canada)
EN55022 Limits and methods of measurement of Radio Interference Characteristics of
Information Technology Equipment. (European Union)
EN55024
Information Technology Equipment – Immunity Characteristics Limits and methods
of measurement. (European Union)
EN55022
Australian Communications Authority, Standard for Electromagnetic Compatibility.
(Australia and New Zealand)
CISPR 22
Limits and methods of measurement of Radio Disturbance Characteristics of
Information Technology Equipment. (International)
CISPR 24 Information Technology Equipment – Immunity Characteristics – Limits and Methods
of Measurement. (International)
VCCI V-3, V-4 Voluntary Control for Interference by Information Technology Equipment. (Japan)
KN-22, KN-24
Korean Communications Commission – Framework Act on Telecommunications and
Radio Waves Act (South Korea)
CNS 13438
Bureau of Standards, Metrology, and Inspection (Taiwan)

Intel NUC5PGYH Specifications

General

Status	Discontinued
BIOS type	EEPROM
Product type	Mini PC
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	UCFF
Removable memory card slot	SDXC with UHS-I support
Supported RAID configuration	N/A
Trusted Platform Module (TPM)	No
HDD size	2.5 \
Storage media	Flash
Card reader integrated	Yes
Total storage capacity	32 GB
Compatible memory cards	SDXC
Embedded storage capacity	32768 MB
Number of storage drives installed	1
Power supply	65 W
DC input voltage	12 - 19 V
Power supply input voltage	19 V
Bus type	DMI
Stepping	C0
Tjunction	90 °C
Product family	Intel NUC
Product series	Intel NUC kit
Processor cache	2 MB
Processor cores	4
Processor model	N3700
System bus rate	2.5 GT/s
Processor family	Intel Pentium N
Processor series	Intel® Pentium N3000 Series for Mobile
Processor socket	BGA 1170
Product codename	Grass Canyon
Processor codename	Braswell
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.4 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2, 1x4, 2x2, 2x1, 4x1
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
Memory types supported by processor	DDR3L-SDRAM
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	12.8 GB/s
Maximum internal memory supported by processor	8 GB
Processor code	SR29E
Processor ARK ID	87261
Processor package size	25 x 27 mm
Intel Smart Connect Technology version	0.00
Intel Identity Protection Technology version	1.00
Chassis type	Nettop
Product color	Black, Silver
Cable lock slot type	Kensington
Number of execution units	16
Discrete graphics card model	Not available
Number of displays supported	2
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	400 MHz
On-board graphics card dynamic frequency (max)	700 MHz
Number of displays supported (on-board graphics)	3
ARK ID	88065
Form factor	UCFF (4\
Audio channels	7.1
Graphics output	VGA (HDB15); HDMI 1.4b
Additional headers	2x USB2.0, AUX_PWR
USB ports quantity	6
Maximum internal memory	8192 MB
Optical drives quantity	0
Export Control Classification Number (ECCN)	5A992C
Intel® Virtualization Technology (Intel® VT)	VT-x, VT-d
Commodity Classification Automated Tracking System (CCATS)	G157815L2
Memory slots	1x SO-DIMM
Internal memory	2 GB
Memory channels	Single-channel
Memory layout (slots x size)	1 x 2 GB
Operating system installed	Windows 10
Pre-installed operating system	Windows 10, 64-bit*
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
HDMI version	1.4b
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
M.2 card slot (wireless)	2230 (E-key)
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 3165
Ethernet LAN data rates	10, 1000, 100 Mbit/s
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	-20 - 70 %
Sustainability certificates	RoHS
Certification	IEC, UL, EN, CAN/CSA-C22.2, CISPR 22, FCC, ICES-003, EN, VCCI V3, KN, CNS, WEEE
Processor included	Intel® Pentium® Processor N3700 (2M Cache, up to 2.40 GHz)
Market segment	Desktop
Last change	63903513
Built-in WiFi	Intel Wireless-AC 3165 + Bluetooth 4.2
Supported storage drives form factor (internal)	2.5\
Harmonized System (HS) code	8471500150

Weight and Dimensions

Depth	111 mm
Width	115 mm
Height	51.6 mm
Weight	- g
