Intel NUC5PGYH

Intel NUC Board NUC5PGYH Technical Product Specification
44
2.2.4.2 Add-in Card Connector
The board supports a M.2 2230 (key type E) module.
• Supports M.2 communication module
2.2.4.3 SDXC Card Reader
The board has a standard Secure Digital (SD) card reader that supports the Secure Digital
eXtended Capacity (SDXC) format, 3.01 specification with UHS-I support. SD Card sizes supported
from 8GB to 128GB.
Table 15. SDXC Card Reader Connector
Pin
Signal Name
Descriptive Name
1 CD Card Detection
2 DATA2 Serial Data 2
3
DATA3
Serial Data 3
4
CMD
Command
5 VSS1 Ground
6 VDD Power (3.3 V)
7
CLK
Serial Clock
8
VSS2
Ground
9 DATA0 Serial Data 0
10 DATA1 Serial Data 1
11
WP
Write Protect
NOTE
The SD card reader is not supported in Microsoft* Windows* 7
