Intel NUC5PGYH

Intel NUC Board NUC5PGYH Technical Product Specification
16
Table 3. Components Shown in Figure 2
Item from
Figure 2 Description
A
Back panel connectors
B
Auxiliary power connector (1.25 mm pitch)
C
VGA connector
D M.2 2230 Module connector
E SDXC slot
F
Front panel dual-port USB 2.0 header (1.25 mm pitch)
G
SATA power connector (1.25 mm pitch)
H SATA 6.0 Gb/s connector
I Front panel USB 3.0 connectors (one blue and one orange charging capable)
J
BIOS security jumper
K
Front panel stereo microphone/headphone jack
L Front panel Consumer Infrared sensor (CIR)
M DDR3L SO-DIMM socket
