Intel NUC5PGYH

Intel NUC Board NUC5PGYH Technical Product Specification
42
2.2.4.1 Signal Tables for the Connectors and Headers
Table 11. VGA Header
Pin
Signal Name
Pin
Signal Name
1 CLK 2 DATA
3 VCC 4 VSYNC
5
HSYNC
6
GND
7
RED
8
GND
9 GREEN 10 GND
11 BLUE 12 KEY
Table 12. SATA Power Header (1.25 mm Pitch)
Pin
Signal Name
1
5 V
2
5 V
3
3.3 V
4
GND
5
GND
NOTE
Connector is Molex* part number 53398-0571, 1.25 mm pitch PicoBlade* header, surface mount,
vertical, lead-free, 5 circuits.
Table 13. Dual-Port Internal USB 2.0 Header (1.25 mm Pitch)
Pin
Signal Name
Pin
Signal Name
1
+5 V DC
2
Data (negative)
3
Data (positive)
4
Ground
5 Ground 6 Data (positive)
7
Data (negative)
8
+5 V DC
NOTE
Connector is Molex part number 53398-0571, 1.25 mm pitch PicoBlade header, surface mount,
vertical, lead-free, 8 circuits.
